Specifications Repeat Robotics 2207 hubmotor for Combat Robots – 1200kv The ultimate hub motor for combat robotics! These 2207 hubmotors come with a battle-hardened magnet ring and are designed to withstand intense impacts. With massive bearings and flexible mounting options, these motors are built for durability and power in any competition. Features Comes with a battle-hardened magnet ring Massive 6704 and 698 bearings Can mount blade on the end or the center of the motor Works with blades from 1/8” thick to 3/8” thick Available in 3 KV options: 1200, 1800, 2400 Recommended for 3S and 4S usage, but the 1200KV motor can be run on 6S with a small enough weapon Specifications Motor Size 2207.5 Weight 55g without wires 59g with full-length wires 65g with blade mounting hardware 79g with 0.25 x 1.5″ shoulder bolt and locknut (for .25″ uprights) Motor Mount Pattern M3x16mm Weapon Mount Screws M4 Overall Dimensions 1.73in max diameter by 1in length KV 1200 Recommended ESC Compatible with most high-performance ESCs for combat robotics Notes A 1/4″ shoulder bolt or similar through shaft is required for use. Without the shoulder bolt, the rotor is not fully constrained and may be damaged. The 1/4″ x 1.5″ shoulder bolt is great for bots with 2x 0.25″ uprights. When designing the blade, ensure the tooth portion lines up with the 2 screws at the top. This provides the most optimal loading scenario with maximum strength. Three-tooth weapon designs are not recommended. Order your high-performance hub motors today and take your combat robot to the next level of power and reliability! These motors are designed to be used in combat, where anything can happen. The manufacturer is unable to accept returns for battle damaged products. ItGresa Robotics is proud to support the builder community by offering and marketing their products. Repeat Robotics is run by a builder who is offering these motors to make the combat robotics scene in the US more competitive.
